Before you begin, familiarize yourself with your smart pen:
- Power Button : Press to turn the pen on/off (see 1.4).
- Pen Nib & Optical Sensor : The writing tip has a built-in optical sensor that reads dot patterns on XNote notebooks. The sensor (oval-shaped part adjacent to the pen tip) should face downwards during use. A protective nib cover is included remove it before first use.
- LED Indicator : A small light that shows the pen's current status (see 1.3).
- Charging Port : Connect the included cable here to charge the pen.
- Cap : Should be placed on the pen when not in use. Storing the pen without the cap may cause degradation due to dust and foreign substances on the optical sensor.
Ink Refill: The pen uses D1-type refills (0.8mm). To replace, pull the pen tip firmly to remove the old refill and insert a new one. Using a non-recommended refill may cause recognition problems.
